FLAMEBLOCK™

REOTEMP’s FlameBlock™ sensor improves safety by eliminating a flame path out of the head, while maintaining a spring loaded stem for positive thermowell contact. Containment of ignition is the standard method of protection with explosion proof assemblies. However, spring loaded stem assemblies universally have a pathway that could allow an ignition to escape the head and ignite ambient flammable materials.

With a welded CSA certified design, Reotemp’s FlameBlockTM Sensor eliminates the flamepath out of the stem assembly – thus eliminating the escape of any ignition which could occur in the head – yet still provides the benefits of having a spring loaded connection. This unique design has found many applications where explosion proof assemblies are required.

  • CSA Certified
  • Spring Loaded Sensor without Direct Flame Path from the Head
  • RTD or Thermocouple
  • Class I, Div. 1, Gr A, B, C, & D
